Functional annotation of Killer-cell Immunoglobulin-like Receptor genotyping data.
Accepts T1K file output and csv for batch analysis, or manual gene entry for single samples.

Single sample: manual gene entry

Check each gene that is present in this individual. Framework genes (FW) and the most common A-haplotype genes (KIR2DL1, KIR2DL3, KIR3DL1, KIR2DS4) are pre-checked as a starting point — uncheck any that are absent. Allele names are optional.

Centromeric region KIR3DL3 → KIR3DP1
Inhib.
Activ.
Inhib. · HLA-C group 1 (C1)
Inhib. · HLA-C group 1 (C1)
Activ.
Pseudo
Inhib. · HLA-C group 2 (C2)
Pseudo
Telomeric region KIR2DL4 → KIR3DL2
Special · HLA-G
Inhib. · HLA-Bw4 (+ some HLA…
Activ. · HLA-Bw4 (putative, …
Inhib.
Inhib.
Activ.
Activ. · HLA-C*05:01, HLA-A*…
Activ. · HLA-C group 2 (C2, weak)
Inhib. · HLA-A3, HLA-A11
▸ Optional: HLA alleles for KIR–HLA interaction

Provide HLA-C, -B, -A, and optionally HLA-G alleles to compute which inhibitory KIRs have their cognate ligand present. Start typing for suggestions.

HLA-G is the ligand for KIR2DL4. If not entered, KIR2DL4 will show "no data" in the interaction table. HLA-G*01:01 is the most common allele.

FW = framework gene (present in all individuals). B = B-haplotype defining gene. Pre-checked genes reflect a typical A-haplotype profile — uncheck any that are absent. Allele format: KIR2DL1*001 or KIR2DL1*00101.
Batch: file upload
No file selected
Select KIR files, optionally together with matching T1K HLA files. HLA files are auto-detected and paired to KIR files by sample name.
▸ Supported file formats

T1K single-sample KIR TSV (one file per sample)

KIR2DL1	2	KIR2DL1*001	133.19	36	KIR2DL1*002	121.30	31
KIR2DL2	1	KIR2DL2*009	0.49	0	.	0	-1

T1K single-sample HLA TSV (paired by filename)

HLA-A	2	HLA-A*23:01	...	60	HLA-A*03:01	...	60
HLA-C	2	HLA-C*06:02	...	60	HLA-C*04:01	...	60

Paired by filename: strip _hla_genotype / _kir_genotype and match what remains.

T1K compiler CSV (wide, multi-sample)

Sample,KIR2DL1,KIR2DL2,...
sample001,KIR2DL1*001/KIR2DL1*002,./.,...

kir-mapper compiler CSV (wide, multi-sample)

Sample,KIR3DL3_CN,KIR3DL3_A1,KIR3DL3_A2,KIR3DL3_status,...
sample001,2,KIR3DL3*00102,KIR3DL3*01601,ambiguous,...
About / Methods
Quick reference: KIR gene functions
GeneTypeHLA ligand
KIR3DL3 FW Inhib. —
KIR2DS2 Activ. —
KIR2DL2 Inhib. HLA-C group 1 (C1)
KIR2DL3 Inhib. HLA-C group 1 (C1)
KIR2DS3 Activ. —
KIR2DP1 FW Pseudo —
KIR2DL1 Inhib. HLA-C group 2 (C2)
KIR3DP1 FW Pseudo —
KIR2DL4 FW Special HLA-G
KIR3DL1 Inhib. HLA-Bw4 (+ some HLA-A Bw4+)
KIR3DS1 Activ. HLA-Bw4 (putative, context-dependent)
KIR2DL5A Inhib. —
KIR2DL5B Inhib. —
KIR2DS5 Activ. —
KIR2DS4 Activ. HLA-C*05:01, HLA-A*11 (weak, context-dependent)
KIR2DS1 Activ. HLA-C group 2 (C2, weak)
KIR3DL2 FW Inhib. HLA-A3, HLA-A11
FW = framework gene, present in all individuals. See About for full annotation and sources.
